額定載重 | t | 0.8 | 1 | 1.6 | 2.5 | 3.2 | 6.3 | 9 |
型號 | LB008 | LB010 | LB016 | LB025 | LB032 | LB063 | LB090 | |
標準起升高度 | m | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
手扳力 | N(kg) | 284(29) | 353(36) | 333(34) | 363(37) | 363(37) | 372(38) | 382(39) |
起重鏈條直徑×行數 | mm | 5.6×1 | 5.6×1 | 7.1×1 | 8.8×1 | 10×1 | 10×2 | 10×3 |
試驗載荷※1 | kg | 1200 | 1500 | 2400 | 3800 | 4800 | 7900 | 11300 |
凈重※2 | kg | 5.7 | 5.9 | 8 | 11.2 | 15 | 26 | 40 |
打包重量 | kg | 6 | 6.2 | 8.3 | 11.6 | 16 | 27 | 42 |
鏈條每增加1m時的增重量 | kg | 0.7 | 0.7 | 1.1 | 1.7 | 2.3 | 4.7 | 7 |
尺寸(mm) | a | 144 | 144 | 159 | 173 | 190 | 190 | 190 |
b | 119 | 119 | 126 | 150 | 159 | 217 | 304 | |
c | 280 | 300 | 335 | 375 | 395 | 540 | 680 | |
d | 245 | 245 | 265 | 265 | 415 | 415 | 415 | |
e | 97 | 97 | 100 | 102 | 112 | 112 | 112 | |
g | 23.5 | 29 | 35 | 36.5 | 39 | 50 | 72.5 | |
s | 35.5 | 42.5 | 42.5 | 47 | 50 | 60 | 85 | |
t | 14 | 15 | 19 | 21 | 24.5 | 34 | 41.5 |
